5215AN Bearing | Loyal
5215AN PDF download| 5215AN interchange NACHI 5215AN | |
| 5215AN cross reference NACHI 5215AN | |
| 5215AN Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 5215AN |
| C | 41.3 mm |
| a | 4.06 mm |
| b | 3.1 mm |
| d | 75 mm |
| D | 130 mm |
| B | 41.3 mm |
| da | 84 mm |
| D1 | 125.22 mm |
| Cy | 6.5 mm |
| Da | 121 mm |
| Dx | 141.5 mm |
| ra | 1.5 mm |
| Width | 41.3 mm |
| r min. | 1.5 mm |
| Weight | 1.91 Kg |
| a (max) | 4.1 mm |
| Bore Size | 75 mm |
| Enclosure | Open |
| Size (mm) | 75x130x41.3 |
| Bore Type | Cylindrical Bore |
| Width (mm) | 41.3 |
| Groove Width | 3.1 mm |
| Configuration | Double Row |
| Bearing number | 5215AN |
| Groove Diameter | 125.2 mm |
| Radial Clearance | 0.010 to 0.030 mm |
| Outside Diameter | 130 mm |
| Static Load Rating | 80,500 N |
| Bore Diameter (mm) | 75 |
| Outer Diameter (mm) | 130 |
| Dynamic Load Rating | 90,000 N |
| Limiting Speed - Oil | 4,300 rpm |
| Fillet Radius/Chamfer | 1.5 mm |
| Limiting Speed - Grease | 3,200 rpm |
| (Grease) Lubrication Speed | 3200 r/min |
| Basic static load rating (C0) | 80,5 kN |
| Basic dynamic load rating (C) | 90 kN |
UCTH212-39J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH212-39J-300
SDI: B-R1/8
SD: 2 7/16
UCTH206-20J-150 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH206-20J-150
SDI: B-1/4-28UNF
SD: 1 1/4
UCTH205-16J-150 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH205-16J-150
SDI: B-1/4-28UNF
SD: 1.00000000
UCTH206-18J-150 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH206-18J-150
SDI: B-1/4-28UNF
SD: 1 1/8
