5215A Bearing | Loyal
5215A PDF download| 5215A interchange NACHI 5215A | |
| 5215A cross reference NACHI 5215A | |
| 5215A Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 5215A |
| D | 130 mm |
| d | 75 mm |
| B | 41.3 mm |
| C | 41.3 mm |
| Cy | 6.5 mm |
| ra | 1.5 mm |
| Dx | 141.5 mm |
| da | 84 mm121 mm |
| Width | 41.3 mm |
| r min. | 1.5 mm |
| Weight | 1.91 Kg |
| Size (mm) | 75x130x41.3 |
| Bore Size | 75 mm |
| Bore Type | Cylindrical Bore |
| Enclosure | Open |
| Width (mm) | 41.3 |
| Configuration | Double Row |
| Bearing number | 5215A |
| Angle (α) | 20 ° |
| Outside Diameter | 130 mm |
| Radial Clearance | 0.010 to 0.030 mm |
| Static Load Rating | 80,500 N |
| Bore Diameter (mm) | 75 |
| Dynamic Load Rating | 90,000 N |
| Outer Diameter (mm) | 130 |
| Limiting Speed - Oil | 4,300 rpm |
| Fillet Radius/Chamfer | 1.5 mm |
| Limiting Speed - Grease | 3,200 rpm |
| (Grease) Lubrication Speed | 3200 r/min |
| Basic static load rating (C0) | 80,5 kN |
| Basic dynamic load rating (C) | 90 kN |
