FYNT 50 F Bearing | Loyal
FYNT 50 F PDF download| FYNT 50 F interchange SKF FYNT 50 F | |
| FYNT 50 F cross reference SKF FYNT 50 F | |
| FYNT 50 F Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | FYNT 50 F |
| N | 14 mm |
| H | 14 mm |
| a | 5 mm |
| L | 192 mm |
| J | 170 mm |
| B | 65 mm |
| T max. | 72.7 mm |
| T - max. | 72.7 mm |
| Category | Bearings |
| Inventory | 0.0 |
| Size (mm) | 50x70x15 |
| Width (mm) | 15 |
| Grub screws | 3 x M 6 |
| A5 | 29.5 mm |
| A3 | 62 mm |
| P2 | 80 kN |
| Pa | 15 kN |
| J1 | 77 mm |
| P1 | 110 kN |
| A2 | 15 mm |
| P3 | 110 kN |
| J3 | 57 mm |
| Da | 105 mm |
| H1 | 65 mm |
| Product Group | M06288 |
| da | 50 mm |
| A1 | 70 mm |
| J2 | 21 mm |
| P2 | 80 kN |
| J4 | 49 mm |
| J3 | 57 mm |
| Pa | 15 kN |
| da | 50 mm |
| A1 | 70 mm |
| A2 | 15 mm |
| H1 | 65 mm |
| Da | 105 mm |
| J1 | 77 mm |
| J2 | 21 mm |
| J4 | 49 mm |
| J5 | 21 mm |
| J6 | 77 mm |
| P3 | 110 kN |
| A3 | 62 mm |
| A5 | 29.5 mm |
| P1 | 110 kN |
| J6 | 77 mm |
| J5 | 21 mm |
| Limiting speed | 3300 r/min |
| Bearing number | FYNT 50 F |
| Mass bearing unit | 4.5 kg |
| Weight / Kilogram | 0 |
| Manufacturer Name | SKF |
| ba max. | 55 mm |
| N4 max. | 6 mm |
| Bore Diameter (mm) | 50 |
| ba min. | 34 mm |
| Outer Diameter (mm) | 70 |
| Minimum Buy Quantity | N/A |
| ba - min. | 34 mm |
| Calculation factor e | 0.24 |
| N4 - max. | 6 mm |
| ba - max. | 55 mm |
| Calculation factor - e | 0.24 |
| Diameter - dm | 70 mm |
| Basic Designation bearing | 22210 E |
| Attachment bolt diameter G | 12 mm |
| Basic dynamic load rating C | 104 kN |
| Basic dynamic load rating - C | 104 kN |
| Fatigue load limit Pu | 11.8 kN |
| Calculation factor Y1 | 2.8 |
| Calculation factor Y2 | 4.2 |
| Tightening torque for grub screws | 8 N·m |
| Grease quantity for relubrication | 4 g |
| Fatigue load limit - Pu | 11.8 kN |
| Calculation factor - Y1 | 2.8 |
| Calculation factor - Y2 | 4.2 |
| Bearing mean diameter dm | 70 mm |
| Tightening torque for attachment bolts | 80 N·m |
| Basic static load rating C0 | 108 kN |
| Basic static load rating - C0 | 108 kN |
