NU3332 Bearing | Loyal
NU3332 PDF download| NU3332 interchange KOYO NU3332 | |
| NU3332 cross reference KOYO NU3332 | |
| NU3332 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | NU3332 |
| C | 136 mm |
| d | 160 mm |
| D | 340 mm |
| B | 136 mm |
| B2 | - |
| Cu | 216 |
| Ew | - |
| d1 | - |
| B1 | - |
| Cr | 1590 |
| Fw | 208 mm |
| C0r | 1890 |
| r min. | 4 mm |
| Weight | 61.5 Kg |
| r(min) | 4 |
| da(min) | - |
| db(min) | 176 |
| db(max) | 200 |
| dc(min) | - |
| r1(min) | 4 |
| dd(min) | - |
| Da(max) | 324 |
| Db(max) | - |
| Db(min) | - |
| r1 min. | 4 mm |
| ra(max) | 3 |
| rb(max) | 3 |
| Oil lub. | 2200 |
| Size (mm) | 160x340x136 |
| Width (mm) | 136 |
| Grease lub. | 1400 |
| Bearing No. | NU3332 |
| Bearing number | NU3332 |
| (Refer.)Mass(kg) | 61.5 |
| Bore Diameter (mm) | 160 |
| Outer Diameter (mm) | 340 |
| (Grease) Lubrication Speed | 1400 r/min |
| Basic static load rating (C0) | 1890 kN |
| Basic dynamic load rating (C) | 1270 kN |
ZK312-34 Tapered bore (with adapter) inch - ZK series
DVIS: A-R1/8
CNSORDERNO: Heavy-duty(3)
SDI: ZK312-34
SD: 2 1/8
UCTH204-12J-150 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH204-12J-150
SDI: B-1/4-28UNF
SD: 3/4
UCTH211-34J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH211-34J-300
SDI: B-R1/8
SD: 2 1/8
UCTH208-25J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH208-25J-300
SDI: B-1/4-28UNF
SD: 1 9/16
