KR 62 XB Bearing | Loyal
KR 62 XB PDF download| KR 62 XB interchange SKF KR 62 XB | |
| KR 62 XB cross reference SKF KR 62 XB | |
| KR 62 XB Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | KR 62 XB |
| G | M 24x1.5 |
| M | 8 mm |
| D | 62 mm |
| d | 24 mm |
| B | 80 mm |
| C | 29 mm |
| SW | 14 mm |
| Size (mm) | 24x62x80 |
| Width (mm) | 80 |
| B1 | 49.5 mm |
| B2 | 11 mm |
| C1 | 0.8 mm |
| d1 | 44 mm |
| G1 | 25 mm |
| M1 | 4 mm |
| Hexagonal nut | M 24x1.5 |
| M1 | 4 mm |
| G1 | 25 mm |
| d1 | 44 mm |
| C1 | 0.8 mm |
| B2 | 11 mm |
| B1 | 49.5 mm |
| Grease fitting | NIP A3x9.5 |
| Limiting speed | 2400 r/min |
| Bearing number | KR 62 XB |
| Mass cam follower | 0.79 kg |
| Bore Diameter (mm) | 24 |
| Lubrication adapter | AP 14 |
| Mass support roller | 0.79 kg |
| Outer Diameter (mm) | 62 |
| r1,2 min. | 1 mm |
| r1,2 - min. | 1 mm |
| Basic dynamic load rating C | 24.6 kN |
| Basic dynamic load rating - C | 24.6 kN |
| Recommended tighthening torque | 220 N·m |
| Fatigue load limit Pu | 5.5 kN |
| Fatigue load limit - Pu | 5.5 kN |
| Basic static load rating C0 | 44 kN |
| Basic static load rating - C0 | 44 kN |
| Maximum static radial loads - F0r | 85 kN |
| Maximum dynamic radial loads - Fr | 58.5 kN |
| Maximum dynamic radial loads Fr max. | 58.5 kN |
| Maximum static radial loads F0r max. | 85 kN |
