- Loyal
- 6012ZZ
6012ZZ Bearing | Loyal
6012ZZ PDF download| 6012ZZ interchange NTN 6012ZZ | |
| 6012ZZ cross reference NTN 6012ZZ | |
| 6012ZZ Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 6012ZZ |
| D | 95 mm |
| d | 60 mm |
| B | 18 mm |
| C | 18 mm |
| rn | 0,5 mm |
| Bore | 2.362 Inch | 60 Millimeter |
| Noun | Bearing |
| da max | 69 mm |
| UNSPSC | 31171504 |
| Weight | 0,414 Kg |
| r min. | 1,1 mm |
| ra max. | 1 mm |
| da min. | 66,5 mm |
| Da max. | 88,5 mm |
| Category | Single Row Ball Bearing |
| Size (mm) | 60x95x18 |
| Snap Ring | No |
| Enclosure | 2 Metal Shields |
| Inventory | 4.0 |
| Width (mm) | 18 |
| bore type: | Round |
| Weight / LBS | 0.913 |
| Product Group | B00308 |
| Cage Material | Steel |
| closure type: | Double Shielded |
| Inch - Metric | Metric |
| Other Features | Deep Groove | Shell Alvania Prelubricated |
| bore diameter: | 60 mm |
| Keyword String | Ball |
| overall width: | 18 mm |
| cage material: | Steel |
| Bearing number | 6012ZZ |
| Rolling Element | Ball Bearing |
| Precision Class | ABEC 1 | ISO P0 |
| Outside Diameter | 3.74 Inch | 95 Millimeter |
| Manufacturer URL | http://www.ntnamerica.com |
| Inner Race Width | 0 Inch | 0 Millimeter |
| Long Description | 60MM Bore; 95MM Outside Diameter; 18MM Outer Race Diameter; 2 Metal Shields; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features |
| Outer Race Width | 0.709 Inch | 18 Millimeter |
| Manufacturer Name | NTN |
| bearing material: | High Carbon Chrome Steel |
| outside diameter: | 95 mm |
| Weight / Kilogram | 0.42 |
| Bore Diameter (mm) | 60 |
| Internal Clearance | C0-Medium |
| internal clearance: | CN |
| Outer Diameter (mm) | 95 |
| Minimum Buy Quantity | N/A |
| Harmonized Tariff Code | 8482.10.50.68 |
| Manufacturer Item Number | 6012ZZ/2AS |
| manufacturer upc number: | 4547359004045 |
| Internal Special Features | No |
| (Grease) Lubrication Speed | 7 000 r/min |
| operating temperature range: | -40 to 250 ºF °F |
| Basic static load rating (C0) | 23,2 kN |
| Basic dynamic load rating (C) | 29,5 kN |
| Maximum Capacity / Filling Slot | No |
UCTH211-35J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH211-35J-300
SDI: B-R1/8
SD: 2 3/16
UCTH212-38J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH212-38J-300
SDI: B-R1/8
SD: 2 3/8
UCTH206-19J-150 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH206-19J-150
SDI: B-1/4-28UNF
SD: 1 3/16
UCTH213-40J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH213-40J-300
SDI: B-R1/8
SD: 2 1/2
