HR32056XJ Bearing | Loyal
HR32056XJ PDF download| HR32056XJ interchange NSK HR32056XJ | |
| HR32056XJ cross reference NSK HR32056XJ | |
| HR32056XJ Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | HR32056XJ |
| D | 420 mm |
| d | 280 mm |
| T | 87 mm |
| B | 87 mm |
| C | 65 mm |
| a | 91,6 mm |
| e | 0.46 |
| Cr | 120000 |
| Y0 | 0.72 |
| db | 305 |
| da | 307 |
| Y1 | 1.3 |
| B_ | 87 |
| Sb | 22 |
| C0 | 2240 |
| Sa | 14 |
| D_ | 420 |
| Z_ | 28 |
| C_ | 65 |
| C0r | 228000 |
| DA_ | 34.218 |
| Iso | 4FC |
| DE_ | 381.684 |
| D_b | 402 |
| DI_ | 316.178 |
| SBRG | 20 |
| SDM_ | 348.931 |
| D_a2 | 374 |
| KBRG | 3111 |
| yobi | HR32056XJ |
| D_a1 | 402 |
| mass | 40.6 |
| TC-RA | 685.5 |
| r min. | 5 mm |
| Weight | 40,6 Kg |
| TC-DA1 | 35.887 |
| TC-DA2 | 32.549 |
| TC-SLR | 64 |
| Da min | 374 mm |
| LangID | 1 |
| ALPHA_ | 17 |
| Db min. | 402 mm |
| Oil rpm | 1000 |
| db max. | 305 mm |
| Da max. | 402 mm |
| ra max. | 4 mm |
| hidYobi | HR32056XJ |
| da min. | 307 mm |
| T-ALP21 | 34 |
| rb max. | 3 mm |
| T-ALP22 | 0 |
| T-ALP23 | 0 |
| GRS rpm | 710 |
| inner r | 5 |
| outer r | 4 |
| r1 min. | 4 mm |
| hidTable | ecat_NSTPRM |
| TC-BET23 | 0 |
| TC-BET21 | 3 |
| inner ra | 4 |
| outer rb | 3 |
| TC-BET22 | 0 |
| Size (mm) | 280x420x87 |
| Width (mm) | 87 |
| Prod_Type3 | TRBSR_MD_A |
| Bearing number | HR32056XJ |
| Bore Diameter (mm) | 280 |
| Outer Diameter (mm) | 420 |
| Calculation factor (e) | 0,46 |
| Calculation factor (Y0) | 0,72 |
| (Oil) Lubrication Speed | 1000 r/min |
| (Grease) Lubrication Speed | 710 r/min |
| Basic dynamic load rating (C) | 1180 kN |
| Basic static load rating (C0) | 2240 kN |
