HR32928J Bearing | Loyal
HR32928J PDF download| HR32928J interchange NSK HR32928J | |
| HR32928J cross reference NSK HR32928J | |
| HR32928J Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | HR32928J |
| D | 190 mm |
| d | 140 mm |
| T | 32 mm |
| B | 32 mm |
| C | 25 mm |
| a | 33,6 mm |
| e | 0.36 |
| Cr | 21000 |
| Y0 | 0.92 |
| db | 150 |
| da | 152 |
| Y1 | 1.7 |
| B_ | 32 |
| Sb | 7 |
| C0 | 390 |
| Sa | 6 |
| D_ | 190 |
| Z_ | 37 |
| C_ | 25 |
| C0r | 39500 |
| DA_ | 12.127 |
| Iso | 2CC |
| DE_ | 177.034 |
| D_b | 184 |
| DI_ | 153.199 |
| SBRG | 29 |
| SDM_ | 165.117 |
| D_a2 | 178 |
| KBRG | 3111 |
| yobi | HR32928J |
| D_a1 | 180 |
| mass | 2.64 |
| TC-RA | 390.5 |
| r min. | 2 mm |
| Weight | 2,64 Kg |
| TC-DA1 | 12.494 |
| TC-DA2 | 11.76 |
| TC-SLR | 23 |
| Da min | 178 mm |
| LangID | 1 |
| ALPHA_ | 13.5 |
| Db min. | 184 mm |
| Oil rpm | 2200 |
| db max. | 150 mm |
| Da max. | 180 mm |
| ra max. | 2 mm |
| hidYobi | HR32928J |
| da min. | 152 mm |
| T-ALP21 | 27 |
| rb max. | 1,5 mm |
| T-ALP22 | 0 |
| T-ALP23 | 0 |
| GRS rpm | 1700 |
| inner r | 2 |
| outer r | 1.5 |
| r1 min. | 1,5 mm |
| hidTable | ecat_NSTPRM |
| TC-BET23 | 0 |
| TC-BET21 | 1 |
| inner ra | 2 |
| outer rb | 1.5 |
| TC-BET22 | 50 |
| Size (mm) | 140x190x32 |
| Width (mm) | 32 |
| Prod_Type3 | TRBSR_MD_A |
| Bearing number | HR32928J |
| Bore Diameter (mm) | 140 |
| Outer Diameter (mm) | 190 |
| Calculation factor (e) | 0,36 |
| Calculation factor (Y0) | 0,92 |
| (Oil) Lubrication Speed | 2200 r/min |
| (Grease) Lubrication Speed | 1700 r/min |
| Basic dynamic load rating (C) | 206 kN |
| Basic static load rating (C0) | 390 kN |
