JHM807045/JHM807012 Bearing | Loyal
JHM807045/JHM807012 PDF download| JHM807045/JHM807012 interchange KOYO JHM807045/JHM807012 | |
| JHM807045/JHM807012 cross reference KOYO JHM807045/JHM807012 | |
| JHM807045/JHM807012 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | JHM807045/JHM807012 |
| B | 36 mm |
| d | 50 mm |
| D | 105 mm |
| T | 37 mm |
| C | 29 mm |
| a | 29,4 mm |
| Db | 100 mm |
| Da | 90 mm |
| r min. | 3 mm |
| Weight | 1,533 Kg |
| db min | 63 mm |
| da min. | 69 mm |
| r2 min. | 2,8 mm |
| rb max. | 2,8 mm |
| ra max. | 3 mm |
| Size (mm) | 50x105x37 |
| Width (mm) | 37 |
| Bearing number | JHM807045/JHM807012 |
| Bore Diameter (mm) | 50 |
| Outer Diameter (mm) | 105 |
| Calculation factor (e) | 0,49 |
| (Oil) Lubrication Speed | 5100 r/min |
| Calculation factor (Y0) | 0,68 |
| (Grease) Lubrication Speed | 3800 r/min |
| Basic dynamic load rating (C) | 149 kN |
| Basic static load rating (C0) | 205 kN |
UCTH213-40J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH213-40J-300
SDI: B-R1/8
SD: 2 1/2
UCTH212-36J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH212-36J-300
SDI: B-R1/8
SD: 2 1/4
UCTH206-20J-150 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH206-20J-150
SDI: B-1/4-28UNF
SD: 1 1/4
UCTH209-27J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH209-27J-300
SDI: B-1/4-28UNF
SD: 1 11/16
