NUP234R Bearing | Loyal
NUP234R PDF download| NUP234R interchange KOYO NUP234R | |
| NUP234R cross reference KOYO NUP234R | |
| NUP234R Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | NUP234R |
| C | 52 mm |
| d | 170 mm |
| D | 310 mm |
| B | 52 mm |
| B2 | - |
| Cu | 98.7 |
| Ew | - |
| d1 | - |
| B1 | - |
| Cr | 754 |
| Fw | 207 mm |
| C0r | 802 |
| r min. | 4 mm |
| Weight | 18.6 Kg |
| r(min) | 4 |
| da(min) | 186 |
| db(min) | 186 |
| db(max) | 204 |
| dc(min) | - |
| r1(min) | 4 |
| dd(min) | - |
| Da(max) | 294 |
| Db(max) | - |
| Db(min) | - |
| r1 min. | 4 mm |
| ra(max) | 3 |
| rb(max) | 3 |
| Oil lub. | 2200 |
| Size (mm) | 170x310x52 |
| Width (mm) | 52 |
| Grease lub. | 1900 |
| Bearing No. | NUP234R |
| Bearing number | NUP234R |
| (Refer.)Mass(kg) | 19.8 |
| Bore Diameter (mm) | 170 |
| Outer Diameter (mm) | 310 |
| (Grease) Lubrication Speed | 1900 r/min |
| Basic static load rating (C0) | 802 kN |
| Basic dynamic load rating (C) | 603 kN |
