5316N Bearing | Loyal
5316N PDF download| 5316N interchange NACHI 5316N | |
| 5316N cross reference NACHI 5316N | |
| 5316N Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 5316N |
| C | 68.3 mm |
| a | 5.69 mm |
| b | 3.5 mm |
| d | 80 mm |
| D | 170 mm |
| B | 68.3 mm |
| da | 92 mm |
| D1 | 163.65 mm |
| Cy | 8.4 mm |
| Da | 158 mm |
| Dx | 185 mm |
| ra | 2 mm |
| Width | 68.3 mm |
| r min. | 2.1 mm |
| Weight | 6.81 Kg |
| a (max) | 5.7 mm |
| Bore Size | 80 mm |
| Enclosure | Open |
| Size (mm) | 80x170x68.3 |
| Bore Type | Cylindrical Bore |
| Width (mm) | 68.3 |
| Groove Width | 3.5 mm |
| Configuration | Double Row |
| Bearing number | 5316N |
| Groove Diameter | 163.7 mm |
| Radial Clearance | 0.010 to 0.030 mm |
| Outside Diameter | 170 mm |
| Static Load Rating | 167,000 N |
| Bore Diameter (mm) | 80 |
| Outer Diameter (mm) | 170 |
| Dynamic Load Rating | 192,000 N |
| Limiting Speed - Oil | 4,000 rpm |
| Fillet Radius/Chamfer | 2.1 mm |
| Limiting Speed - Grease | 2,800 rpm |
| (Grease) Lubrication Speed | 2800 r/min |
| Basic static load rating (C0) | 167 kN |
| Basic dynamic load rating (C) | 192 kN |
