29685/29620 Bearing | Loyal
29685/29620 PDF download| 29685/29620 interchange NSK 29685/29620 | |
| 29685/29620 cross reference NSK 29685/29620 | |
| 29685/29620 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 29685/29620 |
| e | 0.49 |
| d | 73,025 mm |
| D | 112,712 mm |
| T | 25,4 mm |
| B | 25,4 mm |
| C | 19,05 mm |
| a | 26,3 mm |
| Da | 101 mm |
| B_ | 25.4 |
| Db | 109 mm |
| da | 86 mm |
| Y0 | 0.68 |
| db | 80 mm |
| C0 | 152 |
| D_ | 112.712 |
| Z_ | 27 |
| C_ | 19.05 |
| Y1 | 1.2 |
| DE_ | 101.524 |
| SLR | 18 |
| D_a | 101 |
| DI_ | 84.863 |
| DA1 | 9.237 |
| DA2 | 8.283 |
| CUP | 0.273 |
| DA_ | 8.762 |
| D_b | 109 |
| RAr | 173.558 |
| SDM_ | 93.336 |
| KBRG | 3161 |
| yobi | 29685/29620 |
| CONE | 0.62 |
| ALP21 | 36 |
| ALP22 | 0 |
| ALP23 | 0 |
| BETA_ | 1 |
| BET21 | 3 |
| BET23 | 0 |
| BET22 | 3 |
| r min. | 3,5 mm |
| LangID | 1 |
| Weight | 0,893 Kg |
| ALPHA_ | 18 |
| r1 min. | 3,3 mm |
| ra max. | 3,5 mm |
| Oil rpm | 4000 |
| outer r | 3.3 |
| hidYobi | 29685/29620 |
| GRS rpm | 2800 |
| inner r | 3.5 |
| hidTable | ecat_NSTPRI |
| inner ra | 3.5 |
| outer rb | 3.3 |
| ra1 max. | 3,3 mm |
| Size (mm) | 73.025x112.712x25.4 |
| SHOG_yobi | 29685R/29620R |
| Prod_Type3 | TRBSR_ID_A |
| Width (mm) | 25,4 |
| Bearing number | 29685/29620 |
| Bore Diameter (mm) | 73,025 |
| Outer Diameter (mm) | 112,712 |
| Calculation factor (e) | 0,49 |
| (Oil) Lubrication Speed | 4000 r/min |
| Calculation factor (Y0) | 0,68 |
| (Grease) Lubrication Speed | 2800 r/min |
| Basic static load rating (C0) | 152 kN |
| Basic dynamic load rating (C) | 96 kN |
