JM718149/JM718110 Bearing | Loyal
JM718149/JM718110 PDF download| JM718149/JM718110 interchange KOYO JM718149/JM718110 | |
| JM718149/JM718110 cross reference KOYO JM718149/JM718110 | |
| JM718149/JM718110 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | JM718149/JM718110 |
| B | 34 mm |
| d | 90 mm |
| D | 145 mm |
| T | 35 mm |
| C | 27 mm |
| a | 32,7 mm |
| Db | 139 mm |
| Da | 131 mm |
| r min. | 3 mm |
| Weight | 2,122 Kg |
| db min | 99 mm |
| da min. | 105 mm |
| r2 min. | 2,5 mm |
| rb max. | 2,5 mm |
| ra max. | 3 mm |
| Size (mm) | 90x145x35 |
| Width (mm) | 35 |
| Bearing number | JM718149/JM718110 |
| Bore Diameter (mm) | 90 |
| Outer Diameter (mm) | 145 |
| Calculation factor (e) | 0,44 |
| (Oil) Lubrication Speed | 3400 r/min |
| Calculation factor (Y0) | 0,74 |
| (Grease) Lubrication Speed | 2500 r/min |
| Basic dynamic load rating (C) | 194 kN |
| Basic static load rating (C0) | 291 kN |
UCTH206-20J-150 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH206-20J-150
SDI: B-1/4-28UNF
SD: 1 1/4
ZKX11-32 Tapered bore (with adapter) inch - ZK series
DVIS: A-1/4-28UNF
CNSORDERNO: Medium-duty(X)
SDI: ZKX11-32
SD: 2.00000000
ZK311-32 Tapered bore (with adapter) inch - ZK series
DVIS: A-R1/8
CNSORDERNO: Heavy-duty(3)
SDI: ZK311-32
SD: 2.00000000
UCTH204-12J-150 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH204-12J-150
SDI: B-1/4-28UNF
SD: 3/4
