6001ZZ Bearing | Loyal
6001ZZ PDF download| 6001ZZ interchange KOYO 6001ZZ | |
| 6001ZZ cross reference KOYO 6001ZZ | |
| 6001ZZ Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 6001ZZ |
| D | 28 mm |
| d | 12 mm |
| B | 8 mm |
| C | 8 mm |
| Noun | Bearing |
| Bore | 0.472 Inch | 12 Millimeter |
| r min. | 0,3 mm |
| da max | 15 mm |
| UNSPSC | 31171504 |
| Weight | 0,022 Kg |
| ra max. | 0,3 mm |
| Da max. | 26 mm |
| da min. | 14 mm |
| Category | Single Row Ball Bearing |
| Enclosure | 2 Metal Shields |
| Inventory | 0.0 |
| Size (mm) | 12x28x8 |
| Snap Ring | No |
| Width (mm) | 8 |
| Weight / LBS | 0.0485 |
| Inch - Metric | Metric |
| Cage Material | Steel |
| Product Group | B00308 |
| Other Features | Deep Groove |
| Bearing number | 6001ZZ |
| Keyword String | Ball |
| Precision Class | ABEC 1 | ISO P0 |
| Rolling Element | Ball Bearing |
| Manufacturer URL | http://www.koyousa.com |
| Outside Diameter | 1.102 Inch | 28 Millimeter |
| Outer Race Width | 0.315 Inch | 8 Millimeter |
| Long Description | 12MM Bore; 28MM Outside Diameter; 8MM Outer Race Width; 2 Metal Shields; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel |
| Inner Race Width | 0 Inch | 0 Millimeter |
| Manufacturer Name | KOYO |
| Weight / Kilogram | 0.024 |
| Internal Clearance | C0-Medium |
| Bore Diameter (mm) | 12 |
| Outer Diameter (mm) | 28 |
| Minimum Buy Quantity | N/A |
| Harmonized Tariff Code | 8482.10.50.68 |
| Internal Special Features | No |
| (Grease) Lubrication Speed | 27000 r/min |
| Basic static load rating (C0) | 2,4 kN |
| Basic dynamic load rating (C) | 5,1 kN |
| Maximum Capacity / Filling Slot | No |
