5215 Bearing | Loyal
5215 PDF download| 5215 interchange NACHI 5215 | |
| 5215 cross reference NACHI 5215 | |
| 5215 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 5215 |
| D | 130 mm |
| d | 75 mm |
| B | 41.3 mm |
| C | 41.3 mm |
| Cy | 6.5 mm |
| ra | 1.5 mm |
| Dx | 141.5 mm |
| da | 84 mm121 mm |
| Noun | Bearing |
| Bore | 2.953 Inch | 75 Millimeter |
| Width | 1.626 Inch | 41.3 Millimeter |
| UNSPSC | 31171531 |
| r min. | 1.5 mm |
| Weight | 1.91 Kg |
| Category | Angular Contact Ball Bearing |
| Enclosure | Open |
| Bore Type | Cylindrical Bore |
| Inventory | 0.0 |
| Snap Ring | No |
| Bore Size | 75 mm |
| Size (mm) | 75x130x41.3 |
| Width (mm) | 41.3 |
| Weight / LBS | 4.21 |
| Flush Ground | No |
| Configuration | Double Row |
| Inch - Metric | Metric |
| Contact Angle | 20 Degree |
| Cage Material | Steel |
| Product Group | B00152 |
| Bearing number | 5215 |
| Keyword String | Angular Contact |
| Angle (α) | 30 ° |
| Rolling Element | Ball Bearing |
| Precision Class | ABEC 1 | ISO P0 |
| Long Description | 75MM Bore; 130MM Outside Diameter; 41.3MM Width; Open; No Flush Ground; Ball Bearing; Double Row of Balls; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring |
| Manufacturer URL | http://www.nachi.com |
| Outside Diameter | 5.118 Inch | 130 Millimeter |
| Radial Clearance | 0.010 to 0.030 mm |
| Weight / Kilogram | 1.911 |
| Manufacturer Name | NACHI |
| Number of Bearings | 1 (Single) |
| Bore Diameter (mm) | 75 |
| Internal Clearance | C0-Medium |
| Static Load Rating | 85,500 N |
| Outer Diameter (mm) | 130 |
| Dynamic Load Rating | 96,000 N |
| Limiting Speed - Oil | 4,700 rpm |
| Minimum Buy Quantity | N/A |
| Fillet Radius/Chamfer | 1.5 mm |
| Harmonized Tariff Code | 8482.10.50.28 |
| Limiting Speed - Grease | 3,400 rpm |
| Number of Rows of Balls | Double Row |
| Manufacturer Item Number | 5215 BNLS |
| (Grease) Lubrication Speed | 3400 r/min |
| Basic dynamic load rating (C) | 96 kN |
| Basic static load rating (C0) | 85,5 kN |
| Maximum Capacity / Filling Slot | No |
