5212AN Bearing | Loyal
5212AN PDF download| 5212AN interchange NACHI 5212AN | |
| 5212AN cross reference NACHI 5212AN | |
| 5212AN Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 5212AN |
| C | 36.5 mm |
| a | 3.28 mm |
| b | 2.7 mm |
| d | 60 mm |
| D | 110 mm |
| B | 36.5 mm |
| da | 69 mm |
| D1 | 106.81 mm |
| Cy | 5.4 mm |
| Da | 101 mm |
| Dx | 118 mm |
| ra | 1.5 mm |
| Width | 36.5 mm |
| r min. | 1.5 mm |
| Weight | 1.36 Kg |
| a (max) | 3.3 mm |
| Bore Size | 60 mm |
| Enclosure | Open |
| Size (mm) | 60x110x36.5 |
| Bore Type | Cylindrical Bore |
| Width (mm) | 36.5 |
| Groove Width | 2.7 mm |
| Configuration | Double Row |
| Bearing number | 5212AN |
| Groove Diameter | 106.8 mm |
| Radial Clearance | 0.008 to 0.028 mm |
| Outside Diameter | 110 mm |
| Static Load Rating | 58,500 N |
| Bore Diameter (mm) | 60 |
| Outer Diameter (mm) | 110 |
| Dynamic Load Rating | 71,500 N |
| Limiting Speed - Oil | 5,000 rpm |
| Fillet Radius/Chamfer | 1.5 mm |
| Limiting Speed - Grease | 3,800 rpm |
| (Grease) Lubrication Speed | 3800 r/min |
| Basic static load rating (C0) | 58,5 kN |
| Basic dynamic load rating (C) | 71,5 kN |
