25877R/25821 Bearing | Loyal
25877R/25821 PDF download| 25877R/25821 interchange KOYO 25877R/25821 | |
| 25877R/25821 cross reference KOYO 25877R/25821 | |
| 25877R/25821 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 25877R/25821 |
| B | 24,608 mm |
| d | 34,925 mm |
| D | 73,025 mm |
| T | 23,812 mm |
| C | 19,05 mm |
| a | 15,8 mm |
| Db | 68 mm |
| Da | 65 mm |
| r min. | 1,6 mm |
| Weight | 0,475 Kg |
| db min | 40,5 mm |
| da min. | 43 mm |
| r2 min. | 0,8 mm |
| rb max. | 0,8 mm |
| ra max. | 1,6 mm |
| Size (mm) | 34.925x73.025x23.812 |
| Width (mm) | 23,812 |
| Bearing number | 25877R/25821 |
| Bore Diameter (mm) | 34,925 |
| Outer Diameter (mm) | 73,025 |
| Calculation factor (e) | 0,29 |
| (Oil) Lubrication Speed | 7400 r/min |
| Calculation factor (Y0) | 1,14 |
| (Grease) Lubrication Speed | 5600 r/min |
| Basic dynamic load rating (C) | 72,2 kN |
| Basic static load rating (C0) | 87,3 kN |
ZKX12-34 Tapered bore (with adapter) inch - ZK series
DVIS: A-1/4-28UNF
CNSORDERNO: Medium-duty(X)
SDI: ZKX12-34
SD: 2 1/8
UCTH210-31J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH210-31J-300
SDI: B-1/4-28UNF
SD: 1 15/16
UCTH206-18J-150 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH206-18J-150
SDI: B-1/4-28UNF
SD: 1 1/8
