18685/18620 Bearing | Loyal
18685/18620 PDF download| 18685/18620 interchange KOYO 18685/18620 | |
| 18685/18620 cross reference KOYO 18685/18620 | |
| 18685/18620 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 18685/18620 |
| B | 17,462 mm |
| d | 44,45 mm |
| D | 79,375 mm |
| T | 17,462 mm |
| C | 13,495 mm |
| a | 16 mm |
| Db | 74 mm |
| Da | 71 mm |
| r min. | 2,8 mm |
| Weight | 0,34 Kg |
| db min | 49,5 mm |
| da min. | 54 mm |
| r2 min. | 1,6 mm |
| rb max. | 1,6 mm |
| ra max. | 2,8 mm |
| Size (mm) | 44.45x79.375x17.462 |
| Width (mm) | 17,462 |
| Bearing number | 18685/18620 |
| Bore Diameter (mm) | 44,45 |
| Outer Diameter (mm) | 79,375 |
| Calculation factor (e) | 0,37 |
| (Oil) Lubrication Speed | 6400 r/min |
| Calculation factor (Y0) | 0,88 |
| (Grease) Lubrication Speed | 4800 r/min |
| Basic dynamic load rating (C) | 47,1 kN |
| Basic static load rating (C0) | 59,1 kN |
UCTH210-31J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH210-31J-300
SDI: B-1/4-28UNF
SD: 1 15/16
UCTH210-32J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH210-32J-300
SDI: B-1/4-28UNF
SD: 2.00000000
UCTH207-21J-230 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH207-21J-230
SDI: B-1/4-28UNF
SD: 1 5/16
UCTH212-39J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH212-39J-300
SDI: B-R1/8
SD: 2 7/16
