FYTJ 50 TF Bearing | Loyal
FYTJ 50 TF PDF download| FYTJ 50 TF interchange SKF FYTJ 50 TF | |
| FYTJ 50 TF cross reference SKF FYTJ 50 TF | |
| FYTJ 50 TF Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | FYTJ 50 TF |
| N | 19 mm |
| B | 51.6 mm |
| T | 54.6 mm |
| L | 115 mm |
| H | 19 mm |
| d | 50 mm |
| A | 40 mm |
| J | 157 mm |
| Bore | 1.969 Inch | 50 Millimeter |
| Noun | Bearing |
| Seals | M Seal |
| UNSPSC | 31171501 |
| Category | Flange Block |
| Inventory | 0.0 |
| Size (mm) | 50x40x18 |
| Width (mm) | 18 |
| Bolt Spacing | 6.181 Inch | 157 Millimeter |
| Weight / LBS | 5.29 |
| Housing Style | 2 Bolt Flange Block |
| s1 | 32.6 mm |
| Product Group | M06110 |
| Inch - Metric | Metric |
| Da | 101.6 mm |
| A1 | 18 mm |
| A3 | 3.2 mm |
| B4 | 9 mm |
| R1 | 23.5 mm |
| R1 | 23.5 mm |
| RG | 1/4-28 UNF |
| N4 | 2 mm |
| J7 | 20 mm |
| A1 | 18 mm |
| J6 | 127 mm |
| B4 | 9 mm |
| GN | 1/4-28 SAE-LT |
| DN | 6.5 mm |
| s1 | 32.6 mm |
| J6 | 127 mm |
| J7 | 20 mm |
| N4 | 2 mm |
| DN | 6.5 mm |
| SWN | 7 mm |
| Db1 | 107 mm |
| Keyword String | Flanged |
| Db2 | 115 mm |
| Other Features | Single Row | Wide Inner Race | Open End | Has Flinger |
| Rα | 45 ° |
| Bearing number | FYTJ 50 TF |
| Mounting Bolts | 16 Millimeter |
| Db1 | 107 mm |
| Db2 | 115 mm |
| SWN | 7 mm |
| Limiting speed | 4000 r/min |
| Relubricatable | Yes |
| Rolling Element | Ball Bearing |
| Mounting Method | Set Screw |
| Long Description | 2 Bolt Flange Block; 50MM Bore; 157MM Bolt Circle; 157MM Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 51.6MM Length Thru Bore; Relubricatable; M Seal Seals |
| Housing Material | Cast Iron |
| Manufacturer URL | http://www.skf.com |
| Housing material | Cast iron |
| Length Thru Bore | 2.031 Inch | 51.6 Millimeter |
| Mass bearing unit | 2.1 kg |
| Manufacturer Name | SKF |
| Weight / Kilogram | 2.247 |
| Bore Diameter (mm) | 50 |
| Insert Part Number | YAR 210-2F |
| Outer Diameter (mm) | 40 |
| A3 - H14 | 3.2 mm |
| Da - H11 | 101.6 mm |
| Pilot Configuration | No Pilot |
| Rα | 45 ° |
| Minimum Buy Quantity | N/A |
| Housing Configuration | 1 Piece Solid |
| Cartridge Pilot Depth | 0 Inch | 0 Millimeter |
| Harmonized Tariff Code | 8483.20.40.40 |
| Thread - G2 | M10x1 |
| Number of Mounting Holes | 2 |
| Manufacturer Item Number | FYTJ 50 TF |
| Cartridge Pilot Diameter | 0 Inch | 0 Millimeter |
| Expansion / Non-expansion | Non-expansion |
| RG - 1/4-28 UNF | 1/428 UNF |
| Basic dynamic load rating C | 35.1 kN |
| GN - 1/4-28 SAE-LT | 1/428 SAELT |
| Basic dynamic load rating - C | 35.1 kN |
| Thread grub screw G2 | M10x1 |
| Fatigue load limit Pu | 0.98 kN |
| Nominal Bolt Circle Diameter Round | 6.2 Inch | 157 Millimeter |
| Fatigue load limit - Pu | 0.98 kN |
| Hexagonal key size for grub screw N | 5 mm |
| Hexagonal key size for grub screw - H | 5 mm |
| Basic static load rating C0 | 23.2 kN |
| Basic static load rating - C0 | 23.2 kN |
| Recommended tightening torque for grub screw | 16.5 N·m |
| Recommended diameter for attachment bolts, mm G | 16 mm |
| Recommended diameter for attachment bolts, inch G | 0.625 in |
