6312ZZ Bearing | Loyal
6312ZZ PDF download| 6312ZZ interchange NTN 6312ZZ | |
| 6312ZZ cross reference NTN 6312ZZ | |
| 6312ZZ Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 6312ZZ |
| C | 31 mm |
| d | 60 mm |
| B | 31 mm |
| D | 130 mm |
| rn | 0,5 mm |
| Bore | 2.362 Inch | 60 Millimeter |
| Noun | Bearing |
| UNSPSC | 31171504 |
| r min. | 2,1 mm |
| da max | 80,5 mm |
| Weight | 1,73 Kg |
| series: | 63 |
| da min. | 71 mm |
| Da max. | 119 mm |
| ra max. | 2 mm |
| Category | Single Row Ball Bearing |
| Size (mm) | 60x130x31 |
| Snap Ring | No |
| Enclosure | 2 Metal Shields |
| Inventory | 2.0 |
| bore type: | Round |
| Width (mm) | 31 |
| Weight / LBS | 3.779 |
| maximum rpm: | 6300 RPM |
| Cage Material | Steel |
| Product Group | B00308 |
| Inch - Metric | Metric |
| closure type: | Double Shielded |
| Keyword String | Ball |
| fillet radius: | 2 mm |
| Other Features | Deep Groove | Shell Alvania Prelubricated |
| Bearing number | 6312ZZ |
| bore diameter: | 60 mm |
| cage material: | Steel |
| overall width: | 31 mm |
| Rolling Element | Ball Bearing |
| Precision Class | ABEC 1 | ISO P0 |
| finish/coating: | Uncoated |
| Outside Diameter | 5.118 Inch | 130 Millimeter |
| Outer Race Width | 1.22 Inch | 31 Millimeter |
| Inner Race Width | 0 Inch | 0 Millimeter |
| Long Description | 60MM Bore; 130MM Outside Diameter; 31MM Outer Race Diameter; 2 Metal Shields; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features |
| Manufacturer URL | http://www.ntnamerica.com |
| bearing material: | High Carbon Chrome Steel |
| outside diameter: | 130 mm |
| inner ring width: | 31 mm |
| Manufacturer Name | NTN |
| Weight / Kilogram | 1.72 |
| outer ring width: | 31 mm |
| precision rating: | ISO Class 0 |
| Bore Diameter (mm) | 60 |
| Internal Clearance | C0-Medium |
| snap ring included: | Without Snap Ring |
| Outer Diameter (mm) | 130 |
| internal clearance: | CN |
| Minimum Buy Quantity | N/A |
| static load capacity: | 52000 N |
| maximum rpm (grease): | 5400 rpm |
| row type & fill slot: | Single Row Non-Fill Slot |
| dynamic load capacity: | 82000 N |
| Harmonized Tariff Code | 8482.10.50.68 |
| Manufacturer Item Number | 6312ZZ/2AS |
| Internal Special Features | No |
| manufacturer product page: | Click here |
| (Grease) Lubrication Speed | 5 400 r/min |
| operating temperature range: | -40 to 120 ºC |
| Basic dynamic load rating (C) | 82 kN |
| Basic static load rating (C0) | 52 kN |
| Maximum Capacity / Filling Slot | No |
