685/672 Bearing | Loyal
685/672 PDF download| 685/672 interchange KOYO 685/672 | |
| 685/672 cross reference KOYO 685/672 | |
| 685/672 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 685/672 |
| C | 30,162 mm |
| a | 38,6 mm |
| e | 0.47 |
| d | 98,425 mm |
| D | 168,275 mm |
| T | 41,275 mm |
| B | 41,275 mm |
| db | 109.0 |
| da | 116.0 |
| Cr | 282 |
| Da | 149 mm |
| Db | 160 mm |
| Cu | 50.4 |
| Y1 | 1.28 |
| Y0 | 0.70 |
| C0r | 349 |
| a(mm) | 38.6 |
| Weight | 3,51 Kg |
| r(min) | 3.6 |
| db min | 109 mm |
| r min. | 3,6 mm |
| ra max. | 3,6 mm |
| r1(min) | 3.2 |
| rb(max) | 3.2 |
| ra(max) | 3.6 |
| da min. | 116 mm |
| r2 min. | 3,2 mm |
| rb max. | 3,2 mm |
| Oil lub. | 3000 |
| Size (mm) | 98.425x168.275x41.275 |
| Width (mm) | 41,275 |
| Bearing No. | 685/672 |
| Grease lub. | 2200 |
| Bearing number | 685/672 |
| (Refer.)Mass(kg) | 3.51 |
| Bore Diameter (mm) | 98,425 |
| Outer Diameter (mm) | 168,275 |
| Calculation factor (e) | 0,47 |
| Calculation factor (Y0) | 0,7 |
| (Oil) Lubrication Speed | 3000 r/min |
| (Grease) Lubrication Speed | 2200 r/min |
| Basic dynamic load rating (C) | 224 kN |
| Basic static load rating (C0) | 349 kN |
