7834CDT Bearing | Loyal
7834CDT PDF download| 7834CDT interchange CYSD 7834CDT | |
| 7834CDT cross reference CYSD 7834CDT | |
| 7834CDT Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 7834CDT |
| D | 215 mm |
| d | 170 mm |
| B | 22 mm |
| C | 22 mm |
| 2B | 44 mm |
| r min. | 1,1 mm |
| Weight | 3,74 Kg |
| Size (mm) | 170x215x22 |
| Width (mm) | 22 |
| Bearing number | 7834CDT |
| Angle (α) | 15 ° |
| Bore Diameter (mm) | 170 |
| Outer Diameter (mm) | 215 |
| (Grease) Lubrication Speed | 3300 r/min |
| Basic dynamic load rating (C) | 123 kN |
| Basic static load rating (C0) | 204 kN |
UCTH212-36J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH212-36J-300
SDI: B-R1/8
SD: 2 1/4
UCTH207-23J-230 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH207-23J-230
SDI: B-1/4-28UNF
SD: 1 7/16
ZKX12-34 Tapered bore (with adapter) inch - ZK series
DVIS: A-1/4-28UNF
CNSORDERNO: Medium-duty(X)
SDI: ZKX12-34
SD: 2 1/8
UCTH207-21J-230 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH207-21J-230
SDI: B-1/4-28UNF
SD: 1 5/16
