K32X39X18H Bearing | Loyal
K32X39X18H PDF download| K32X39X18H interchange KOYO K32X39X18H | |
| K32X39X18H cross reference KOYO K32X39X18H | |
| K32X39X18H Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | K32X39X18H |
| Fw | 32 mm |
| Ew | 40 mm |
| Bc | 18 mm |
| Cr | 25.8 |
| Cu | 6.05 |
| P/S | S |
| C0r | 38.2 |
| Noun | Bearing |
| Bore | 1.26 Inch | 32 Millimeter |
| Width | 0.709 Inch | 18 Millimeter |
| UNSPSC | 31171512 |
| Weight | 0.033 Kg |
| Retainer | Yes |
| Oil lub. | 14000 |
| Category | Needle Non Thrust Roller Bearing |
| Inventory | 0.0 |
| Separable | No |
| Component | Roller Assembly Only |
| Enclosure | Not Applicable |
| Closed End | Not Applicable |
| Grease lub. | 8900 |
| Bearing No. | K32X39X18H |
| Shaft(max.) | 32.000 |
| Shaft(min.) | 31.989 |
| Weight / LBS | 0.073 |
| Housing(max.) | 39.025 |
| Housing(min.) | 39.009 |
| Inch - Metric | Metric |
| Product Group | B04144 |
| Self Aligning | No |
| Other Features | Radial Roller | Hardened Steel Cage |
| Bearing number | K32X39X18H |
| Keyword String | Needle |
| Thrust Bearing | No |
| Rolling Element | Needle Roller Bearing |
| Outside Diameter | 1.535 Inch | 39 Millimeter |
| Long Description | 32MM Bore; 39MM Outside Diameter; 18MM Width; Needle Roller Bearing; Roller Assembly Only; No Self Aligning; Retainer; Single Row of Rollers; No Separable |
| Manufacturer URL | http://www.koyousa.com |
| (Refer.)Mass(kg) | 0.033 |
| Manufacturer Name | KOYO |
| Weight / Kilogram | 0.03 |
| Bore Diameter (mm) | 32 |
| Outer Diameter (mm) | 40 |
| Minimum Buy Quantity | N/A |
| Harmonized Tariff Code | 8482.40.00.00 |
| (Oil) Lubrication Speed | 14000 r/min |
| Manufacturer Item Number | K32X39X18H |
| Number of Rows of Rollers | Single Row |
| (Grease) Lubrication Speed | 8900 r/min |
| Basic static load rating (C0) | 38.2 kN |
| Basic dynamic load rating (C) | 25.8 kN |
