K14X18X13 Bearing | Loyal
K14X18X13 PDF download| K14X18X13 interchange KOYO K14X18X13 | |
| K14X18X13 cross reference KOYO K14X18X13 | |
| K14X18X13 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | K14X18X13 |
| Fw | 14 mm |
| Ew | 18 mm |
| Bc | 13 mm |
| Cr | 9.73 |
| Cu | 1.90 |
| P/S | S |
| C0r | 12.5 |
| Noun | Bearing |
| Bore | 0.551 Inch | 14 Millimeter |
| Width | 0.512 Inch | 13 Millimeter |
| UNSPSC | 31171512 |
| Weight | 0.006 Kg |
| Retainer | Yes |
| Oil lub. | 29000 |
| Category | Needle Non Thrust Roller Bearing |
| Inventory | 0.0 |
| Separable | No |
| Component | Roller Assembly Only |
| Enclosure | Not Applicable |
| Closed End | Not Applicable |
| Grease lub. | 19000 |
| Bearing No. | K14X18X13 |
| Shaft(max.) | 14.000 |
| Shaft(min.) | 13.992 |
| Weight / LBS | 0.013 |
| Housing(max.) | 18.017 |
| Housing(min.) | 18.006 |
| Inch - Metric | Metric |
| Product Group | B04144 |
| Self Aligning | No |
| Other Features | Radial Roller | Steel Cage |
| Bearing number | K14X18X13 |
| Keyword String | Needle |
| Thrust Bearing | No |
| Rolling Element | Needle Roller Bearing |
| Outside Diameter | 0.709 Inch | 18 Millimeter |
| Long Description | 14MM Bore; 18MM Outside Diameter; 13MM Width; Needle Roller Bearing; Roller Assembly Only; No Self Aligning; Retainer; Single Row of Rollers; No Separable |
| Manufacturer URL | http://www.koyousa.com |
| (Refer.)Mass(kg) | 0.006 |
| Manufacturer Name | KOYO |
| Weight / Kilogram | 0.014 |
| Bore Diameter (mm) | 14 |
| Outer Diameter (mm) | 18 |
| Minimum Buy Quantity | N/A |
| Harmonized Tariff Code | 8482.40.00.00 |
| (Oil) Lubrication Speed | 29000 r/min |
| Manufacturer Item Number | K14X18X13 |
| Number of Rows of Rollers | Single Row |
| (Grease) Lubrication Speed | 19000 r/min |
| Basic static load rating (C0) | 12.5 kN |
| Basic dynamic load rating (C) | 9.73 kN |
