32019XU Bearing | Loyal
32019XU PDF download| 32019XU interchange NTN 32019XU | |
| 32019XU cross reference NTN 32019XU | |
| 32019XU Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 32019XU |
| B | 32 mm |
| e | 0.44 |
| d | 95 mm |
| D | 145 mm |
| T | 32 mm |
| C | 24 mm |
| a | 31,5 mm |
| Y2 | 1.36 |
| Sa | 6 mm |
| d1 | 121 mm |
| Y0 | 0.75 |
| Sb | 8 mm |
| Mass | 1.83 kg |
| ra max | 2 mm |
| Weight | 1,83 Kg |
| Ca min | 6 mm |
| Db min | 140 mm |
| r min. | 2 mm |
| Da max | 136.5 mm |
| rs min | 2 mm |
| Da min | 130 mm |
| Cb min | 8 mm |
| db min | 105 mm |
| da max | 105 mm |
| r1s min | 1.5 mm |
| ra max. | 2 mm |
| r1a max | 1.5 mm |
| Db min. | 140 mm |
| db max. | 105 mm |
| Da max. | 136,5 mm |
| da min. | 105 mm |
| r1 min. | 1,5 mm |
| ra1 max. | 1,5 mm |
| Category | Bearings |
| Size (mm) | 95x145x32 |
| Inventory | 0.0 |
| Nlim (oil) | 3,100 rpm |
| Width (mm) | 32 |
| Nlim (grease) | 2,300 rpm |
| Product Group | B04334 |
| Bearing number | 32019XU |
| Static load, C0 | 280 kN |
| Dynamic load, C | 171 kN |
| ISO 355 reference | T4CC095 |
| Weight / Kilogram | 0 |
| Manufacturer Name | NTN |
| Bore Diameter (mm) | 95 |
| Outer Diameter (mm) | 145 |
| Minimum Buy Quantity | N/A |
| Calculation factor (e) | 0,44 |
| Fatigue limit load, Cu | 32.3 kN |
| (Oil) Lubrication Speed | 3 100 r/min |
| Calculation factor (Y0) | 0,75 |
| (Grease) Lubrication Speed | 2 300 r/min |
| Rating life coefficient, A2 | 1 |
| Basic static load rating (C0) | 280 kN |
| Basic dynamic load rating (C) | 171 kN |
| Max operating temperature, Tmax | 120 °C |
| Min operating temperature, Tmin | -40 °C |
| Characteristic cage frequency, FTF | 0.45 Hz |
| Characteristic inner ring frequency, BPFI | 15.87 Hz |
| Characteristic outer ring frequency, BPF0 | 13.13 Hz |
| Characteristic rolling element frequency, BSF | 10.07 Hz |
