32019JR Bearing | Loyal
32019JR PDF download| 32019JR interchange KOYO 32019JR | |
| 32019JR cross reference KOYO 32019JR | |
| 32019JR Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 32019JR |
| D | 145 mm |
| d | 95 mm |
| T | 32 mm |
| B | 32 mm |
| C | 24 mm |
| a | 31,2 mm |
| e | 0.44 |
| Cr | 229 |
| Y0 | 0.75 |
| Y1 | 1.36 |
| Cu | 42.6 |
| C0r | 287 |
| Bore | 3.74 Inch | 95 Millimeter |
| Noun | Bearing |
| a(mm) | 31.2 |
| Da min | 130 mm |
| da max | 105 mm |
| Weight | 1,88 Kg |
| r min. | 2 mm |
| r(min) | 2 |
| UNSPSC | 31171516 |
| Db(min) | 140 |
| db(max) | 105 |
| Da(max) | 136.5 |
| Da(min) | 130 |
| r1(min) | 1.5 |
| Sa(min) | 6 |
| Sb(min) | 8 |
| ra(max) | 2 |
| rb(max) | 1.5 |
| da(min) | 105 |
| ra max. | 2 mm |
| Db min. | 140 mm |
| Da max. | 136,5 mm |
| da min. | 105 mm |
| r2 min. | 1,5 mm |
| rb max. | 1,5 mm |
| Oil lub. | 3300 |
| Category | Tapered Roller Bearings Assembly |
| Size (mm) | 95x145x32 |
| Component | Assembly |
| Inventory | 0.0 |
| Width (mm) | 32 |
| Grease lub. | 2500 |
| Bearing No. | 32019JR |
| Basic Number | 32019 |
| Weight / LBS | 4.145 |
| Inch - Metric | Metric |
| Product Group | B04334 |
| Other Features | High Load Capacity |
| Keyword String | Tapered |
| Assembly Width | 1.26 Inch | 32 Millimeter |
| Bearing number | 32019JR |
| Precision Class | Standard |
| (Refer.)Mass(kg) | 1.88 |
| Outside Diameter | 5.709 Inch | 145 Millimeter |
| Manufacturer URL | http://www.koyousa.com |
| Long Description | Assembly; Standard Precision; 95MM Bore; 145MM Outside Diameter; 32MM Assembly Width; Single Row of Rollers |
| Weight / Kilogram | 2.03 |
| Manufacturer Name | KOYO |
| Bore Diameter (mm) | 95 |
| Outer Diameter (mm) | 145 |
| Minimum Buy Quantity | N/A |
| Calculation factor (e) | 0,44 |
| Number of Tapered Rows | Single Row |
| Harmonized Tariff Code | 8482.20.00.00 |
| Flange Outside Diameter | 0 Inch | 0 Millimeter |
| (Oil) Lubrication Speed | 3300 r/min |
| Calculation factor (Y0) | 0,75 |
| Manufacturer Item Number | 32019JR |
| (Grease) Lubrication Speed | 2500 r/min |
| Basic static load rating (C0) | 287 kN |
| Basic dynamic load rating (C) | 182 kN |
UCTH208-24J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH208-24J-300
SDI: B-1/4-28UNF
SD: 1 1/2
UCTH206-20J-150 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH206-20J-150
SDI: B-1/4-28UNF
SD: 1 1/4
UCTH212-39J-300 with Setscrew(inch)
CNSORDERNO: Normal-duty(2)
TOGN: UCTH212-39J-300
SDI: B-R1/8
SD: 2 7/16
