32017JR Bearing | Loyal
32017JR PDF download| 32017JR interchange KOYO 32017JR | |
| 32017JR cross reference KOYO 32017JR | |
| 32017JR Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 32017JR |
| D | 130 mm |
| d | 85 mm |
| T | 29 mm |
| B | 29 mm |
| C | 22 mm |
| a | 28 mm |
| e | 0.44 |
| Cr | 189 |
| Cu | 35.5 |
| Y0 | 0.75 |
| Y1 | 1.36 |
| C0r | 234 |
| Bore | 3.346 Inch | 85 Millimeter |
| Noun | Bearing |
| a(mm) | 28.0 |
| Da min | 117 mm |
| da max | 94 mm |
| Weight | 1,38 Kg |
| r min. | 1,5 mm |
| r(min) | 1.5 |
| UNSPSC | 31171516 |
| Db(min) | 125 |
| db(max) | 94 |
| Da(max) | 121.5 |
| Da(min) | 117 |
| r1(min) | 1.5 |
| Sa(min) | 6 |
| Sb(min) | 7 |
| ra(max) | 1.5 |
| rb(max) | 1.5 |
| da(min) | 93.5 |
| ra max. | 1,5 mm |
| Db min. | 125 mm |
| Da max. | 121,5 mm |
| da min. | 93,5 mm |
| r2 min. | 1,5 mm |
| rb max. | 1,5 mm |
| Oil lub. | 3700 |
| Category | Tapered Roller Bearings Assembly |
| Size (mm) | 85x130x29 |
| Component | Assembly |
| Inventory | 0.0 |
| Width (mm) | 29 |
| Grease lub. | 2800 |
| Bearing No. | 32017JR |
| Basic Number | 32017 |
| Weight / LBS | 3.042 |
| Inch - Metric | Metric |
| Product Group | B04334 |
| Other Features | High Load Capacity |
| Keyword String | Tapered |
| Assembly Width | 1.142 Inch | 29 Millimeter |
| Bearing number | 32017JR |
| Precision Class | Standard |
| (Refer.)Mass(kg) | 1.38 |
| Manufacturer URL | http://www.koyousa.com |
| Long Description | Assembly; Standard Precision; 85MM Bore; 130MM Outside Diameter; 29MM Assembly Width; Single Row of Rollers |
| Outside Diameter | 5.118 Inch | 130 Millimeter |
| Weight / Kilogram | 1.49 |
| Manufacturer Name | KOYO |
| Bore Diameter (mm) | 85 |
| Outer Diameter (mm) | 130 |
| Minimum Buy Quantity | N/A |
| Number of Tapered Rows | Single Row |
| Harmonized Tariff Code | 8482.20.00.00 |
| Calculation factor (e) | 0,44 |
| Flange Outside Diameter | 0 Inch | 0 Millimeter |
| (Oil) Lubrication Speed | 3700 r/min |
| Calculation factor (Y0) | 0,75 |
| Manufacturer Item Number | 32017JR |
| (Grease) Lubrication Speed | 2800 r/min |
| Basic static load rating (C0) | 234 kN |
| Basic dynamic load rating (C) | 150 kN |
