32014JR Bearing | Loyal
32014JR PDF download| 32014JR interchange KOYO 32014JR | |
| 32014JR cross reference KOYO 32014JR | |
| 32014JR Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 32014JR |
| D | 110 mm |
| d | 70 mm |
| T | 25 mm |
| B | 25 mm |
| C | 19 mm |
| a | 23,6 mm |
| e | 0.43 |
| Cr | 136 |
| Cu | 24.8 |
| Y0 | 0.76 |
| Y1 | 1.38 |
| C0r | 163 |
| Bore | 2.756 Inch | 70 Millimeter |
| Noun | Bearing |
| a(mm) | 23.6 |
| Da min | 98 mm |
| da max | 78 mm |
| Weight | 0,884 Kg |
| r min. | 1,5 mm |
| r(min) | 1.5 |
| UNSPSC | 31171516 |
| Db(min) | 105 |
| db(max) | 78 |
| Da(max) | 101.5 |
| Da(min) | 98 |
| r1(min) | 1.5 |
| Sa(min) | 5 |
| Sb(min) | 6 |
| ra(max) | 1.5 |
| rb(max) | 1.5 |
| da(min) | 78.5 |
| ra max. | 1,5 mm |
| Db min. | 105 mm |
| Da max. | 101,5 mm |
| da min. | 78,5 mm |
| r2 min. | 1,5 mm |
| rb max. | 1,5 mm |
| Oil lub. | 4400 |
| Category | Tapered Roller Bearings Assembly |
| Size (mm) | 70x110x25 |
| Component | Assembly |
| Inventory | 0.0 |
| Width (mm) | 25 |
| Grease lub. | 3300 |
| Bearing No. | 32014JR |
| Basic Number | 32014 |
| Weight / LBS | 1.949 |
| Inch - Metric | Metric |
| Product Group | B04334 |
| Other Features | High Load Capacity |
| Keyword String | Tapered |
| Assembly Width | 0.984 Inch | 25 Millimeter |
| Bearing number | 32014JR |
| Precision Class | Standard |
| (Refer.)Mass(kg) | 0.884 |
| Manufacturer URL | http://www.koyousa.com |
| Long Description | Assembly; Standard Precision; 70MM Bore; 110MM Outside Diameter; 25MM Assembly Width; Single Row of Rollers |
| Outside Diameter | 4.331 Inch | 110 Millimeter |
| Weight / Kilogram | 0.89 |
| Manufacturer Name | KOYO |
| Bore Diameter (mm) | 70 |
| Outer Diameter (mm) | 110 |
| Minimum Buy Quantity | N/A |
| Number of Tapered Rows | Single Row |
| Harmonized Tariff Code | 8482.20.00.00 |
| Calculation factor (e) | 0,43 |
| Flange Outside Diameter | 0 Inch | 0 Millimeter |
| (Oil) Lubrication Speed | 4400 r/min |
| Calculation factor (Y0) | 0,76 |
| Manufacturer Item Number | 32014JR |
| (Grease) Lubrication Speed | 3300 r/min |
| Basic static load rating (C0) | 163 kN |
| Basic dynamic load rating (C) | 108 kN |
