32012JR Bearing | Loyal
32012JR PDF download| 32012JR interchange KOYO 32012JR | |
| 32012JR cross reference KOYO 32012JR | |
| 32012JR Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 32012JR |
| e | 0.43 |
| d | 60 mm |
| D | 95 mm |
| T | 23 mm |
| B | 23 mm |
| C | 17,5 mm |
| a | 21 mm |
| Cr | 108 |
| Y0 | 0.77 |
| Y1 | 1.39 |
| Cu | 19.0 |
| C0r | 127 |
| a(mm) | 21.0 |
| r(min) | 1.5 |
| Da min | 85 mm |
| r min. | 1,5 mm |
| Weight | 0,621 Kg |
| da max | 67 mm |
| Sa(min) | 4 |
| r2 min. | 1,5 mm |
| db(max) | 67 |
| Da(max) | 86.5 |
| Da(min) | 85 |
| Db(min) | 91 |
| da min. | 68,5 mm |
| r1(min) | 1.5 |
| ra(max) | 1.5 |
| rb(max) | 1.5 |
| da(min) | 68.5 |
| rb max. | 1,5 mm |
| ra max. | 1,5 mm |
| Db min. | 91 mm |
| Da max. | 86,5 mm |
| Sb(min) | 5.5 |
| Oil lub. | 5200 |
| Category | Bearings |
| Inventory | 0.0 |
| Size (mm) | 60x95x23 |
| Width (mm) | 23 |
| Bearing No. | 32012JR |
| Grease lub. | 3900 |
| Product Group | B04334 |
| Bearing number | 32012JR |
| (Refer.)Mass(kg) | 0.621 |
| Weight / US pound | 1.34 |
| Manufacturer Name | KOYO |
| Bore Diameter (mm) | 60 |
| Outer Diameter (mm) | 95 |
| Minimum Buy Quantity | N/A |
| Calculation factor (e) | 0,43 |
| Calculation factor (Y0) | 0,77 |
| (Oil) Lubrication Speed | 5200 r/min |
| (Grease) Lubrication Speed | 3900 r/min |
| Basic static load rating (C0) | 127 kN |
| Basic dynamic load rating (C) | 86,1 kN |
