KRE 47 PPA Bearing | Loyal
KRE 47 PPA PDF download| KRE 47 PPA interchange SKF KRE 47 PPA | |
| KRE 47 PPA cross reference SKF KRE 47 PPA | |
| KRE 47 PPA Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | KRE 47 PPA |
| G | M 20x1.5 |
| C | 24 mm |
| c | 1 mm |
| M | 6 mm |
| D | 47 mm |
| d | 24 mm |
| B | 66 mm |
| SW | 10 mm |
| Category | Ball Bearings |
| Inventory | 0.0 |
| Size (mm) | 24x47x66 |
| Width (mm) | 66 |
| B1 | 40.5 mm |
| d1 | 36.5 mm |
| Product Group | B04120 |
| B1 | 40.5 mm |
| B2 | 9 mm |
| B3 | 18 mm |
| C1 | 0.8 mm |
| M1 | 4 mm |
| B2 | 9 mm |
| G1 | 21 mm |
| M1 | 4 mm |
| G1 | 21 mm |
| Hexagonal nut | M 20x1.5 |
| d1 | 36.5 mm |
| C1 | 0.8 mm |
| B3 | 18 mm |
| Bearing number | KRE 47 PPA |
| Limiting speed | 3000 r/min |
| Grease fitting | NIP A2x7.5 |
| Mass cam follower | 0.4 kg |
| Manufacturer Name | SKF |
| Weight / Kilogram | 0.406 |
| Bore Diameter (mm) | 24 |
| Outer Diameter (mm) | 47 |
| Lubrication adapter | AP 10 |
| Mass support roller | 0.4 kg |
| Minimum Buy Quantity | N/A |
| r1,2 min. | 1 mm |
| r1,2 - min. | 1 mm |
| Basic dynamic load rating C | 14.7 kN |
| Basic dynamic load rating - C | 14.7 kN |
| Recommended tighthening torque | 120 N·m |
| Fatigue load limit Pu | 2.9 kN |
| Fatigue load limit - Pu | 2.9 kN |
| Basic static load rating C0 | 24.5 kN |
| Basic static load rating - C0 | 24.5 kN |
| Maximum dynamic radial loads - Fr | 23.6 kN |
| Maximum static radial loads - F0r | 33.5 kN |
| Maximum dynamic radial loads Fr max. | 23.6 kN |
| Maximum static radial loads F0r max. | 33.5 kN |
