NUP1052 Bearing | Loyal
NUP1052 PDF download| NUP1052 interchange KOYO NUP1052 | |
| NUP1052 cross reference KOYO NUP1052 | |
| NUP1052 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | NUP1052 |
| C | 65 mm |
| d | 260 mm |
| D | 400 mm |
| B | 65 mm |
| B2 | - |
| Cu | 110 |
| Ew | - |
| d1 | - |
| B1 | - |
| Cr | 819 |
| Fw | 296 mm |
| C0r | 979 |
| r min. | 4 mm |
| Weight | 29.2 Kg |
| r(min) | 4 |
| da(min) | 276 |
| db(min) | 276 |
| db(max) | 292 |
| dc(min) | - |
| r1(min) | 4 |
| dd(min) | - |
| Da(max) | 384 |
| Db(max) | - |
| Db(min) | - |
| r1 min. | 4 mm |
| ra(max) | 3 |
| rb(max) | 3 |
| Oil lub. | 1700 |
| Size (mm) | 260x400x65 |
| Width (mm) | 65 |
| Grease lub. | 1400 |
| Bearing No. | NUP1052 |
| Bearing number | NUP1052 |
| (Refer.)Mass(kg) | 29.2 |
| Bore Diameter (mm) | 260 |
| Outer Diameter (mm) | 400 |
| (Grease) Lubrication Speed | 1400 r/min |
| Basic static load rating (C0) | 979 kN |
| Basic dynamic load rating (C) | 651 kN |
